Rename an ingested table
Applies to: API-based pipeline authoring
By default, target tables created by Lakeflow Connect managed ingestion pipelines have the same name as the source tables. However, you can optionally rename an ingested table. For example, if you ingest an object into two target tables in the same schema, you'll have to rename one of the target tables to differentiate between them (duplicates aren't supported). If you rename a table in your pipeline, it becomes an API-only pipeline, and you can no longer edit the pipeline in the UI.
Example: Google Analytics
- Databricks Asset Bundles
- Databricks notebook
- Databricks CLI
YAML
resources:
pipelines:
pipeline_ga4:
name: <pipeline-name>
catalog: <target-catalog> # Location of the pipeline event log
schema: <target-schema> # Location of the pipeline event log
ingestion_definition:
connection_name: <connection>
objects:
- table:
source_url: <project-id>
source_schema: <property-name>
destination_catalog: <target-catalog>
destination_schema: <target-schema>
destination_table: <custom-target-table-name> # Table rename
Google Analytics:
Python
pipeline_spec = """
{
"name": "<pipeline>",
"ingestion_definition": {
"connection_name": "<connection>",
"objects": [
{
"table": {
"source_catalog": "<project-id>",
"source_schema": "<property-name>",
"source_table": "<source-table>",
"destination_catalog": "<target-catalog>",
"destination_schema": "<target-schema>",
"destination_table": "<custom-target-table-name>",
}
}
]
}
}
"""
JSON
{
"resources": {
"pipelines": {
"pipeline_ga4": {
"name": "<pipeline>",
"catalog": "<target-catalog>",
"schema": "<target-schema>",
"ingestion_definition": {
"connection_name": "<connection>",
"objects": [
{
"table": {
"source_url": "<project-id>",
"source_schema": "<property-name>",
"destination_catalog": "<destination-catalog>",
"destination_schema": "<destination-schema>",
"destination_table": "<custom-destination-table-name>"
}
}
]
}
}
}
}
}
Example: Salesforce
- Databricks Asset Bundles
- Databricks notebook
- Databricks CLI
YAML
resources:
pipelines:
pipeline_sfdc:
name: <pipeline-name>
catalog: <target-catalog> # Location of the pipeline event log
schema: <target-schema> # Location of the pipeline event log
ingestion_definition:
connection_name: <connection>
objects:
- table:
source_schema: <source-schema>
source_table: <source-table>
destination_catalog: <target-catalog>
destination_schema: <target-schema>
destination_table: <custom-target-table-name> # Table rename
Python
pipeline_spec = """
{
"name": "<pipeline>",
"ingestion_definition": {
"connection_name": "<connection>",
"objects": [
{
"table": {
"source_catalog": "<source-catalog>",
"source_schema": "<source-schema>",
"source_table": "<source-table>",
"destination_catalog": "<target-catalog>",
"destination_schema": "<target-schema>",
"destination_table": "<custom-target-table-name>",
}
}
]
}
}
"""
JSON
{
"resources": {
"pipelines": {
"pipeline_sfdc": {
"name": "<pipeline>",
"catalog": "<target-catalog>",
"schema": "<target-schema>",
"ingestion_definition": {
"connection_name": "<connection>",
"objects": [
{
"table": {
"source_schema": "<source-schema>",
"source_table": "<source-table>",
"destination_catalog": "<destination-catalog>",
"destination_schema": "<destination-schema>",
"destination_table": "<custom-destination-table-name>"
}
}
]
}
}
}
}
}
Example: Workday
- Databricks Asset Bundles
- Databricks notebook
- Databricks CLI
YAML
resources:
pipelines:
pipeline_workday:
name: <pipeline>
catalog: <target-catalog> # Location of the pipeline event log
schema: <target-schema> # Location of the pipeline event log
ingestion_definition:
connection_name: <connection>
objects:
- report:
source_url: <report-url>
destination_catalog: <target-catalog>
destination_schema: <target-schema>
destination_table: <custom-target-table-name> # Table rename
Python
pipeline_spec = """
{
"name": "<pipeline>",
"ingestion_definition": {
"connection_name": "<connection>",
"objects": [
{
"report": {
"source_url": "<report-url>",
"destination_catalog": "<target-catalog>",
"destination_schema": "<target-schema>",
"destination_table": "<custom-target-table-name>",
}
}
]
}
}
"""
JSON
{
"resources": {
"pipelines": {
"pipeline_workday": {
"name": "<pipeline>",
"catalog": "<target-catalog>",
"schema": "<target-schema>",
"ingestion_definition": {
"connection_name": "<connection>",
"objects": [
{
"report": {
"source_url": "<report-url>",
"destination_catalog": "<destination-catalog>",
"destination_schema": "<destination-schema>",
"destination_table": "<custom-destination-table-name>"
}
}
]
}
}
}
}
}
